Control

Showtec 50786 DB-1-8

8 Channel DMX booster

• DMX splitter for 8 outputs

• Electrical isolation between in and output

• DMX Indication LEDs on in-& outputs

• 3P XLR outputs

• M10 nut at backside for truss clamps

The DB models from Showtec are universal DMX-512 optical splitters. They are designed to distribute the incoming DMX signal, in daisy chain configurations, into multiple separate outputs with an additional –Tru" port. They can be mounted in any 19" rack or into the truss by the M10 nut on the rear end of the unit. It has clear LEDs to show the DMX signal status of each output and input. There are two models available, DB-1-4 with 4 outputs and 3 & 5 Pole XLR connectors and the DB-1-8 which has 8 outputs with 3P XLR connectors.

Price: £105.00+VAT (£126.00 Including VAT at 20%)

Quantity:

Add 13A Plug

Showtec 50348 Multi Exchanger

Multi Exchanger 72CH. DMX/Analog 3 & 5 pin Convert the signal from DMX-512 to 72CH. ANALOGUE output.

• Convert the signal from MIDI to 72CH. ANALOGUE output.

• The front panel alpha-numeric display shows the DMX start address & programming options.

• The last scene remains when DMX disappears.

• Pre-store a scene and is available for emergency.

• Memory backup with EEPROM.

• CHASE function can be selected from1 to 72 channel&speed control.

• Select ANALOGUE output from +(-)10V, +(-)12V and +(-)15V.

• Receive NOTE ON/OFF signal of MIDI.

D Type 25 pin to 4 x 8 PIN adaptor cable require.

Wired to Europlug

Price: £140.00+VAT (£168.00 Including VAT at 20%)

Quantity:

Add 13A Plug

SHOWTEC - 50810 NET-8/5

8 Channel Artnet/Klingnet node, 5p XLR

The Showtec NET-8/3 and NET-8/5 nodes are cutting-edge network routing devices which convert ArtNET to DMX512 and back. A maximum of 4096 channels can be transported over a single CAT5. This makes the NET-8/x suitable for small to large scale events. The NET-8/x embeds a built-in network switch to allow it to be used as a Ethernet repeater as well as 8 isolated DMX-512 universes which can be used as a input or output. All settings can be done by the easy-to-use menu on the graphic display and buttons on the front. Settings can also be arranged via the webbrowser possibility, which gives you (remote) access through your computer or laptop and your network

Supports both ArtNET or KlingNET protocol

1Gbps data speed

8 universes DMX input or output

High Speed Network in and output

Webbrowser connection

Quantity:

SHOWTEC - 50809 NET-8/3

8 Channel Artnet/Klingnet node, 3p XLR

The Showtec NET-8/3 and NET-8/5 nodes are cutting-edge network routing devices which convert ArtNET to DMX512 and back. A maximum of 4096 channels can be transported over a single CAT5. This makes the NET-8/x suitable for small to large scale events. The NET-8/x embeds a built-in network switch to allow it to be used as a Ethernet repeater as well as 8 isolated DMX-512 universes which can be used as a input or output. All settings can be done by the easy-to-use menu on the graphic display and buttons on the front. Settings can also be arranged via the webbrowser possibility, which gives you (remote) access through your computer or laptop and your network

Supports both ArtNET or KlingNET protocol

1Gbps data speed

8 universes DMX input or output

High Speed Network in and output

Webbrowser connection

Price: £425.00+VAT (£510.00 Including VAT at 20%)

Quantity:
